D E S I G N :
• Good surface finish is produced by the 2 precision
ground cutting edges with Chipbreakers
• Chipbreakers reduce cutting pressure and noise levels
• Excellent chipflow and lower heat retention is provided
by the 2 flute design with Chipbreakers
• Submicron, corrosion resistant, extended life carbide
provides increased durability and resistance to resin
build-up
• 30º Helix design with plunging capability
A P P L I C AT I O N :
• Chipbreakers reduce the size of chips and improve
chipflow, allowing for higher feed rates and tool life in
plywood, chipboard and solid wood
• Chipbreakers reduce tear-out in plywood,
solid wood and loose core materials
• Good finish on hardwoods, softwoods, chipboard
and plywood materials
• Commonly used for rebates, dadoes/grooving and
pocketing operations on raw panels, plywood and
solid wood
• Reduces fuzzing and tear-out along the
bottom face of the board
• Increased cutting edge life when frequently
accelerating/decelerating or performing multiple
passes such as “Onion skinning”
• Upcut spiral improves chip ejection from
the cutting path
• For improved dust extraction use with an
Aerotech (page FC21)
